There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

1. Conducting copper conductor corresponding to class 1 or 2 according to GOST 22483-2012:
   - single-wire round 1.5 ... 50 mm2;
   - single-wire sector 25 ... 50 mm2;
   - stranded round 16 ... 50 mm2;
   - multiwire round 70 ... 240 mm2 for single- and two-core cables;
   - or multi-wire sector 25 ... 240 mm2.
2. Insulation of PVC conductors of low fire hazard of nominal 0.8 ... 1.9 mm thick.
3. Filling of low-risk internal PVC plastic compound and outer gaps between twisted insulated conductors, stranded cables with round conductors.
4. Polypropylene fastening tape, spirally applied to twisted strands cables with sector veins.
5. PVC sheath of reduced fire hazard corresponding to
Obp-2 category according to GOST 23286-78, nominal thickness 1.2 ... 2.5 mm.

Cable decoding VVGng-LS - 1kV
_VVGng-LS - 1kV
copper conductor
low flammability PVC insulation
low flammability PVC sheath
no protective cover ("bare")
reduced smoke and gas emission (low smoke)
rated voltage 1 kV
