Suitable for connecting electric vehicle charging devices and charging infrastructure to transmit power to electric vehicles, equipped with a certain number of signal lines, control lines, power auxiliary lines, etc. to ensure accurate control and safe operation of the entire charging process. Charging cables are generally used in charging stations, parking lots, hotels, residential areas, garages, and other areas. Portable charging cables can be placed inside vehicles.

Conductor material: Stranded bare copper in accordance with IEC60228 cl.5 pt.4

Core wire insulation: EV1-2 halogen-free mixture

Core wire recognition: Color coding follows VDE-0293-308

Outer sheath: EVM-1 type halogen-free mixture

Sheath color: Black (RAL9005) or Orange (RAL 2004)

Rated voltage: 300/500V (H05BZ5-F), 450/750V (H07BZ5-F)

Test voltage: 2000V (H05BZ5-F), 2500V (H07BZ5-F)

Minimum bending radius: fixed 6 * D, moving 10 * D

Working temperature: Static -40 ° C~+90 ° C, Dynamic -30 ° C~+90 ° C

  Flame retardant rating: Complies with IEC60332-1-2
