There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

NYY power cables are designed for energy supply in cable conduits, power plants, industrial and distribution boards, and user networks. It can also be used in brick walls and concrete (non compact concrete), except for situations where vibration and swinging are required. NYY cables can be installed outdoors, laid underground, in water, and indoors to prevent mechanical damage. This cable is UV resistant and can be used outdoors.

Standards and Certification
VDE-0276 Part-603 & Part-627, HD 603.1 & 627 S1, IEC 60502, VDE 0482-332-1-2, DIN EN60332-1-2/IEC 60332-1, CE low voltage 73/23/EEC and 93/68/EEC directives, ROHS certification

Cable structure
-Solid or multi stranded bare copper conductor
-Following DIN VDE 0295 cl.1/cl. 2, BS 6360 cl.1/cl. 2, IEC 60228 cl.1/cl. 2
-PVC insulation DIV4 class, following HD 603.1
-Color coding follows DIN VDE 0293-308, 0276-603/HD 186
-Core color of 3+1/2 conductor
J category: yellow green (1/2), brown, black, gray
Class O: Blue (1/2), Brown, Black, Grey
-PVC outer sheath DMV5 class, following HD 603.1

Technical Features
-Working voltage: 600/1000 V
-Test voltage: 4000 V
-Dynamic bending radius: 15 x Ø
-Static bending radius: 12 x Ø
-Operating temperature during application: -5 º C to+50 º C
-Fixed installation temperature: -40 º C to+70 º C
-Flame retardant: IEC 60332.1
-Insulation resistance:>100 M Ω x km
