There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

Application:
The cable is used in fire extinguishing systems, sprinklers, control panels, and exit lights in high-rise buildings, hotels, hospitals, sub-ways, and public facilities

Construction:
1.    Conductor - Plain annealed class 2 stranded or class 5 flexible copper
2.    Fire Resistant layer - Mica Tape
3.    Insulation - Low smoke halogen-free (LSZH)

Cross Section:
Class 2 copper conductor: 2C1.0~2C2.5mm2
Class 5 copper conductor: 2C1.0~2C1.5mm2

Temperature characteristics:
Conductor operating temperature: -15ºC~90ºC
Min. temperatrue laying condition: 0ºC

Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min

Color:
Red, black or according to customer requirements
