There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

The quality of submersible pump cables is particularly important because if a cable that is 100 or even hundreds of meters underwater fails, it is quite troublesome to remove the cable. The manpower and financial resources required far exceed the price of the cable itself. Therefore, the material and process of submersible pump cables directly affect the service life and cost budget of the cable.

Conductor: multi strand twisted filament conductor, compliant with VDE 0295 and 1EC 60288 Class 5 conductors

Insulation: Special rubber mixture

Core wire: colored or encoded core wire, 3-core or above with yellow green dual color wire (optional)

Core wire arrangement: straight or plum blossom

Sheath: Special rubber compound

Sheath color: Color, various colors can be selected according to customer needs

Rated voltage: ＜ 0.5m ㎡: 300V/300V; ≥0.5m㎡:300/500V

Test voltage: 2000V

Small bending radius: Fixed installation: 6 × D; Mobile use: 20xD

Usage temperature: Fixed installation (-25 ℃/70 ℃); Mobile installation (0 ℃/70 ℃)
