There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

Conductor:
Class 2 stranded plain annealed copper conductor to BS EN 60228: 2005 (previously BS6360)
Insulation:
XLPE (Cross-Linked Polyethylene)
Bedding:
LSZH (Low Smoke Zero Halogen)
Armouring:

Single Core: AWA (Aluminium Wire Armour)
Multi Core: SWA (Steel Wire Armour)
Sheath:
LSZH (Low Smoke Zero Halogen)
Sheath Colour:
Black
Voltage Rating:
600/1000V
Temperature Rating:
0° C to +90° C
Minimum Bending Radius:

1.5mm² - 16mm² :
6 x overall diameter

25mm² And above:
8 x overall diameter
Core Identification:

1 Core: Brown
2 Cores: Brown, Blue
3 Cores: Brown, Black, Grey
4 Cores: Blue, Brown, Black, Grey
5 Cores: Green/Yellow, Blue, Brown, Black, Grey
Alternative core identification: White Cores with Black numbers
