There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

1. Rated voltages U0/U: 450/750V
2. Permissible Max. continuous operating temperature of conductor:
3. PVC insulated: 70ºC;XLPE insulated: 90ºC.
4. Upon short circuit (Max. Duration time 5s) the Max.temperature of conductor not higher than:
5. PVC insulated: 160ºC; XLPE insulated 250ºC.
6. Ambient temperature of installation not less than 0ºC.
7. Preferred permissible bending radium:
8. For non-armored cable, not less than 6 times of cable diameter;
9. For armored or copper-tape-screened cable, not less than 12 times of cable diameter;
10.For screened flexible cable, not less than 6 times of cable diameter.
