Application

This product is suitable for wind turbine generator system middle turbine and the installation of fixed tower or similar systems with twist resistant environment, can adapt to different weather conditions and special occasions, and has the characteristics of use in the cold, high temperature and high humidity in special environment.

Special cable for wind power generator in addition to meet the performance of ordinary cable, also must meet the basic requirements of small bending radius, frequent torsion, the wind power generator cable used in climate condition is bad, commonly used in China's northern region, the climate was cold, and the larger temperature difference between day and night, so the cable must also meet the environment the temperature of -45ºC to 50ºC, running temperature conditions for -40ºC and 50ºC.

Technical performance

1.The conductor shall comply with the requirements of fifth kinds of soft round stranded conductors specified in GB/T 3956-2008
2.The highest operating temperature of Conductor: ethylene propylene rubber insulation 70ºC, 90ºC; silicone rubber insulation 90ºC.
3.The finished cable shall be to withstand the normal temperature torsion test and the low temperature torsion test specified in Appendix B of GB/T 29631-2013.
4.The finished cable shall be able to withstand weight test as specified in Appendix C of GB/T 29631-2013.
5.The finished cable shall be able to withstand the low temperature bending test specified in Appendix D of GB/T 29631-2013.
