There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

1. Usage

It is used to transmit and distribute power on the power line of A. C. Rated voltage 0.6/1-3.6/6KV.

2. Characteristics

1) The Max. Rated temperature of the conductor is 70.

2) The Max. Temperature of the conductor of the cables cannot exceed 160 when short circuit (Max. Duration: 5s).

3) The cables can be laid without the limit of fall with enough mechanical pull, but the single core cable cannot be laid in iron tube or cannot be fixed by circled iron tools around the cables.

4) The laying temperature of cables should not be lower than 0, When the ambient temperature is under 0, the cables should be heated up to 0 or higher with certain methods.
