AWG | Bending Radius | Insulation Thickness | Nominal Overall Diameter | Nominal DC Resistance |
(Inches) | (Inches) 30/600V | Inches | OHM/1000ft @ 20°C | |
18 | 0.60 | 0.030/0.045 | 0.10/0.13 | 6.66 |
16 | 0.68 | 0.030/0.045 | 0.11/0.14 | 4.18 |
14 | 0.72 | 0.030/0.045 | 0.12/0.15 | 2.624 |
12 | 0.8 | 0.030/0.045 | 0.14/0.17 | 1.65 |
10 | 0.88 | 0.030/0.045 | 0.16/0.19 | 1.038 |
8 | 1 | 0.030/0.045 | 0.20/0.23 | 0.653 |
6 | 1.25 | 0.030/0.045 | 0.22/0.25 | 0.411 |
4 | 1.45 | 0.030/0.045 | 0.26/0.29 | 0.258 |
