1.Application

For fixed installation indoors, outdoors, in the ground and in water.

2.Construction

Conductor: Plain annealed copper, Class 2, Stranded circular, compacted or sectored

Insulation: Cross-linked Polyethylene (XLPE) compound

Insulation colour:

2 cores: Brown, Blue

3 cores: Brown, Black, Grey or Brown, Blue, Green/Yellow

4 cores: Brown, Black, Grey, Blue

5 cores: Brown, Black, Grey, Blue, Green/Yellow or White with black numbering

Assembly: Cores cabled together with filler and bound with binder tape

Outer sheath: Low-Smoke Zero-Halogen (LSZH) compound with anti-termite characteristics and UV resistant

Outer sheath colour: Black

3.Standard

Design specification: IEC60502-1

Conductor: IEC60228, BS EN60228

Flame retardancy: IEC60332-3-22, BS EN60332-3-22

Low-Smoke Zero-Halogen: IEC61034-2, BS EN61034-2, IEC60754-1, IEC60754-2, BS EN60754-1, BS EN60754-2
