1: Technic data

High flexible shielded power cable for drag chains according to DIN VDE. IEC

Temperature range:

flexing from -30 °C to +80 °C

fixed from -50 °C to +80 °C

Nominal voltage:

supply cores:

Uo/U 0,6/1 kV to DIN VDE

1 kV to cUL

control cores:

250 V to DIN VDE

1 kV to cUL

Test voltage a.c.:Insulation resistance: at 20 °C ≥ 20 MΩ x km

supply cores:

core/core 4000 V

core/screen 4000 V

Minimum bending radius:Aprobation UL/CSA

flexing inf. 7,5 x cable diameter

fixed approx. 6 x cable diameter

2: Application

Flexible drag chain cable is applicable for dry or damp indoor environment, suitable for installation under condition of free continuous reciprocating movement that is free of strong stress sustained release or compulsive lead, especially suitable for locations where require frequent bending operation in industrial operating environment, such as woodworking machinery, machine tool processing equipment, logistics conveyer system, crane and son on.It has short pair-twisted pitch, good anti-crosstalk performance, is suitable for configuration of high-speed single loop line.

3: Description

We Special PUR hose line, halogen-free, shielded according to DIN VDE 0281 part 13
For use in dry, moist and wet rooms as well as outside Suitable for frequent stroke and bending loads on permanently moving machine parts Good oil resistance Resistant to weathering influences, ozone, hydrolysis, oxygen, UV radiation, microbes, coolant emulsion, bases and hydraulic fluids

4: Pur drag chain cable Chracteristics

Fine stranded copper core according to DIN VDE 0295 and IEC 60228 class 6.

Core insulation TPE

Cores are wrapped with soft textile tape

Color code:Core wrapping with fleece

supply cores black with print and green/yellow

control cores (in pairs) black with print BR1, BR2

Control cores are shielded in pairs of tinned copper braided screening

Overall shield tinned copper braided screening, approx 85% coverage

Special outer sheath PUR, orange color

Resistant to oil according to DIN VDE 0472 part 803 test B

Self-extinguishing and flame-retardant according to DIN VDE 0482 /IEC 60332-1
