There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

Scope of application:

This product is suitable for DC ripple voltage 1000V and below lines. It is suitable for all kinds of special mobile cables for welding equipment.
Product features:

Soft, resistant to bending and a certain degree of weather resistance.
Executive standard:

GB/T 5013-2008 Additional standard for rubber insulated cables with rated voltage 450/750V and below;
Use characteristics;

Rated voltage:

The rated voltage is 0.2kV, and the highest voltage of the DC ripple system should not exceed 1kV. Working temperature The long-term allowable maximum working temperature of cable conductor is 60ºC.

CONSTRUCTION
Conductor
Generally to Class 6 flexible copper conductor according to IEC 60228 BS EN 60228 (previously BS 6360)
Separator
PET (Polyester Tape)
Sheath
The rubber compound,

Technical data
Voltage Rating
100V
Working temperature:65ºC

Temperature Rating
Fixed: -40°C to +85°C
Flexed: -20°C to +85°C
Minimum Bending Radius
Flexed: 6 x overall diameter
