There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

Application:
Multi-core heat resistant cables, for mobile and portable receivers.

Cables work best in home rooms, kitchens, offices, in light working conditions, for light portable devices (for example radio receivers, table and standing lamps, office machines). It is not suitable for heating, cooking and heating appliances. It is not suitable for outdoor installations outdoors, in industrial or agricultural buildings, for portable tools except for household appliances.

Construction:

• Cores: Made of soft copper wire, multi-wire flexible class 5 according to PN-EN 60228

• Insulation: TI3 acc. EN 50363-3

• Coating: TM3 acc. EN 30363-4-1

• Coating color: White, black or other

• Identification of veins:

• 2-wire: blue, brown

• 3-wire: green-yellow, blue, brown

• 4-wire: green-yellow, brown, black, gray

Characteristic:

• Explanation of symbolism:

• H03V2V2-F - Cable manufactured in accordance with the harmonized standard (H) for rated voltage 300 / 300V (03) with insulation from heat-resistant PVC (V2) and a heat-resistant PVC (V2) sheath with flexible multi-stranded conductors (F)

• H03V2V2H2-F - Cable manufactured in accordance with the harmonized standard (H) for rated voltage 300 / 300V (03) with insulation from heat-resistant PVC (V2) and PVC coating with heat resistant (V2) flat (H2) with flexible multi-conductor cables (F)

• Maximum temperature of the conductor during cable operation: + 90°C

• The minimum ambient temperature for permanently laid cables: -30°C

• The minimum ambient temperature for laying cables: -5°C

• Maximum core temperature during short circuit: + 150°C

• Test voltage 50 Hz: 2000V

• Minimum bending radius: 6 x D, D - outer diameter of the cable or smaller dimension of the flat cable

• Standard packaging: In reels of 50 or 100 m and on drums of 500 or 1000 m. It is possible to offer other lengths of sections and types of packaging
