There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

These cables are especially suited to use for the appliance with medium mechanical stress in households, kitchens and offices, also for household appliances in damp and wet areas, e. g. refrigerators, washing machines, spin driver etc. As far as this cable is admitted to the relevant specifications of the equipment.
These cables are suited to be used for cooking and heating apparatus under the condition that cable does not come in direct contact with hot parts of the apparatus and no other influences of heat.
The cables are suitable for fixed installation in furnitures, partition walls, decoration covering and in hollow spaces of prefabricated building parts.
They are not qualified for use in outdoors or for use with industrial and farmer machineries, exceptionally in tailoring, etc.

Technical characteristics

- Operating Voltage: 300/500V
- Test Voltage: 2000V
- Dynamic Bending Radius: 7.5 x Φ
- Static Bending Radius: 4 x Φ
- Working Temperature: -5ºC ~ +70ºC
- Static Operating Temperature: -40ºC ~ +70ºC
- Short Circuit Temperature: +160ºC
- Fire Resistance: IEC 60332.1
- Insulation Resistance: 20 M Ω x km

Standards and Certification

- VDE0281, CENELEC HD21.5
- 0.5 - 2.5mm² according to BS6500,4.0mm² according to BS7919,6.0mm² according to BS7919,VDE0281,CENELECHD21.5,CE Low Voltage73/23/EEC & 98/68 EEC
- ROHS Certificate

There are many types of cables, but the website demonstration is limited. If you need any cable, please contact us and we accept customization.
