There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

Application scope:
As a connection and control cable for electric hoists, it is suitable for various electrical installations in dry or humid indoor environments. Due to its unique flexible design, it is also suitable for installation or fixed installation under left and right discontinuous movements that can be forcibly guided without stress relief. (Not used for elevator cable up and down lifting)

Product Features:
Huangma rope is added between the cable cores to resist load, and a layer of non-woven fabric buffer is wrapped between the core wire and the protective sleeve. In the case of ultra-high length, there are also two load-bearing steel wire ropes to choose from (with a breaking force of up to 10.4KN and a height of up to 150 meters). Due to the use of modified PVC sheath, it has better tensile and tear resistance than general rubber material, while maintaining flexibility
Better product performance and safer use

Cable structure:
Conductor: Multi strand ultra-fine precision twisted oxygen free copper wire, compliant with VDE0295CLASS 5 standard
Insulation: Special mixed PVC insulation
Color: Colorful numerical representation, in accordance with JJSC3306 standard
      Black numbers and white numbers, in compliance with IEC227 standard
      (If including yellow and green grounding wires, please explain)
Inner lining layer: special non-woven fabric wrapped for cushioning
Steel wire: one or two torsion free self-supporting steel wires that bear the tension generated during operation Sheath: Special mixed PVC sheath, black (RAL9005)

Detailed parameters:
Rated voltage: less than or equal to 1.5mm: 300/500V;   Greater than 1.5mm: 450/750V
Test voltage: less than or equal to 1.5mm: 2500V;   Greater than 1.5mm: 3000V
Temperature range for use: -15 ℃ to+70 ℃
Bending radius: 20 times the outer diameter of the cable
  Self supporting steel cable, also known as hoist handle cable or hoist wire
