There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

Application:
Instrument cable is mainly used in the computer network and control systems, need Strong anti-jamming performance basic device and instrumentation, as the connection wires. Capacity of resisting disturbance is relatively strong.
Applicable Standards: BS 5308, IEC60502-1, BS EN 50288-7,ANSI / ICEA S-73-532 or the standards agreed by both of the customers and us.
Production Scope:
Voltage: 1KV or below
Conductor type: Stranded or solid (class 1, 2, and 5)
Nominal Cross Section Area: 0.5mm2 to 6mm2
Pair No.: 1-61pairs
Construction:
Conductor: Copper or tinned copper
Insulation: PVC /PE /XLPE
Individual Screen (optional): Aluminum foil with drain wire, Copper wire braiding, Copper tape
Overall Screen: Aluminum foil with drain wire, Copper wire braiding, Copper tape
Armor (optional): Steel Tape / Steel Wire
Sheath: PVC, PE, LSHF, or other special requirements
Core's Color:
One Pair: Black/White Pair
Two Pairs and above: black/White Pairs with Numbers 1, 2….n or color.
Color of Sheath: Black, blue or customer designated.
* We can design and produce according to client's requirement.

There are many types of cables, but the website demonstration is limited. If you need any cable, please contact us and we accept customization.
