There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

Applied to fixed power and control cables in the following environments

Installed outdoors, underground, in water, indoors, in cable ducts, in industrial and distribution cabinets for power plants, and in user networks
Used in fixed devices without mechanical damage

When PVC cables are buried directly without additional and appropriate underground protection in accordance with VDE standards: the normal installation depth is 0.6 meters, but at least 0.8 meters below the road
When used in concrete, cables can be used for cable * working temperature+70 ℃

Conductor: Circular conductor (abbreviation: r) in accordance with VDE0295/IEC228 Class 1 or Class 2 conductors; Fan-shaped conductor; Multi stranded conductor;

Insulation: PVC core wire insulation, DIV4 complies with HD603.1 regulations

Core wire: Core wires are twisted together to form a cable

Sheath: PVC outer sheath, DMV5 complies with HD603.1 regulations (black or customized according to customer requirements)

Working temperature: Fixed installation: -40 º C to 70 º C

      Occasional movement: -5 º C to 50 º C;

Bending radius: Single core: 15X cable outer diameter;

      Multi core: 12X outer diameter

Rated voltage: working voltage 0.6/1KV;

Test cable 4000V;

Flame retardant properties: PVC self extinguishing and flame retardancy test method B according to VDE0472 Part 804 and IEC 60332-1 regulations
