In the cable/pipeline package of articulated robots, as well as in gantry robots used for power drag chains or mechanical moving parts automation equipment in the automotive industry, the cable outer diameter is small, saving installation space. It uses a sturdy PUR outer sheath, which is more durable in harsh environments with mechanical stress, and can resist various lubricants containing mineral oil components, diluted acid, alkaline water solutions, and other chemical media. It has a wide temperature range and is suitable for harsh climate environments. It is wear-resistant, scratch resistant, flame retardant, and has higher oil resistance. It maintains softness and low viscosity at low temperatures.

Conductor: Multiple strands of thin bare copper wire bundled together with a soft structure conductor should be twisted first and then twisted in strands

Insulation: TPE

Cable formation: Core layer twisted

Center: The cable comes with an additional centerline pair: 2 core wires twisted together and wrapped in PTFE aluminum foil, with a surface tin plated copper wire shielding layer (optional)

Shielding: Tin plated copper wire braided shielding

Inner protective material: Imported special mixed sheath specialized material

Outer sheath: The sheath adopts high tear resistant imported brand PUR material extrusion process, with the purpose of fully filling the rubber material into the edge gap of the cable core, making the cable dense;

Working temperature:;

    Fixed installation: -50 ° C to+80 ° C (UL/CSA:+80 ° C)

Mobile installation: -45 ° C; To  +80°C  (UL/CSA: +80°C)

Bending radius:;
Mobile installation: 6.5 x outer diameter;

Fixed installation: 4 x outer diameter

Rated voltage:;
IEC U0/U: 450/750 V

UL/CSA: 600 V

Test cable: 3000V;
Combustion test: flame retardant, in accordance with IEC 60332-1-2, UL VW-1, cable combustion test, CSA FT 1， Non flame retardant, compliant with IEC 60332-3-22A standard

Core wire identification:;

    Colored core wire identification, in accordance with VDE 0293-308

    6 cores and above: Black core wire with white numerical code

Anti torsion: The torsion conforms to the maximum ± 360 °/m

Inductance: approximately 0.7 mH/km

Mutual capacitance:

    Core/Chip: Approximately 100 nF/km

    Core/screen approximately 120 nF/km

G=including yellow green grounding protection core wire

X=Excluding yellow green grounding protection core wire
