There are many types of cables, and the website cannot display all of them. We have most cables in stock, and special cables can be customized. If you have any cable needs, please contact us.

APPLICATION
For general use in domestic premises, kitchens, offices and industrial equipment where the cables are subjected to low mechanical stress. Suitable for dry, damp and wet installations,  including temporary outdoor power. Supply of electricity and communications in buildings and other civil engineering works with the objective of limiting the generation and spread of fire.

PRODUCTS STANDARD
BS EN 50525-2-21:20211

CHARACTERISTICS
Voltage Rating U/Uo   300/500V
Temperature Rating    Operating: -40°C to +60°C   Minimum installation and use temperature: -25°C
Maximum temperature of short circuit: +200°C
Minimum Bending Radius   Fixed: 4 x overall diameter

CONSTRUCTION
Conductor    Class 5 flexible copper conductor
Insulation      EPR (Ethylene Propylene Rubber) EI4
Sheath         PCP (Polychloroprene) EM2

Core Identification
2 core:      Blue    Brown
3 core:      Green/Yellow Blue     Brown
4 core:    Green/Yellow  Brown    Black
Sheath Colour
 Black
