Working Environment:
Maximum operating temperature in fixed application : -20 deg C - + 80 deg C
Maximum operating temperature in mobile application : -5 deg C - + 70 deg C
conductor :  +70 deg C
Environment : suitable for use in dry & humid areas

Electrical properties:
Nominal voltage: 300/500 V
Test Voltage :  2000 V
Conductor resistance :In accordance with IEC 228 class 6
Insulation resistance : > 20 MOhms x km

Additional information:
Minimum bending radius : Mobile application - 10 x cable thickness
Maximum suspended height: 80 meters
Tensile strength : 150kg each carrier element
Oil resistance :  According to VDE 0472
