Application: Fire Resistant - Mains and Sub-Mains, Fire Alarm Systems, Essential Services

Construction:
1.    Conductor - Plain annealed class 5 flexible copper
2.    Fire Resistant layer - Mica Tape
3.    Insulation - Cross-linked low-smoke halogen-free polyolefin compound (X-HF-110)
4.    Filler - Flame retardant material
5.    Binder Tape - Low smoke halogen-free flame retardant tape
6.    Outer sheath - Cross-linked low-smoke halogen-free polyolefin compound (HFS-110-TP)

Cross Section:
2 core: 1.5~400mm2
3 core: 1.5~400mm2
4 core: 1.5~400mm2
5 core: 1.5~400mm2
2 core + earth: 1.5~400mm2
3 core + earth: 1.5~400mm2
4 core + earth: 1.5~400mm2

Temperature characteristics:
Conductor operating temperature: -40ºC~110ºC
Min. temperatrue laying condition: 0ºC

Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min

Color:
Insulation:

2 core: Red, Black
3 core: Red, White, Blue
4 core: Red, White, Blue, Black
5 core: Red, White, Blue, Black, Y/G
2 core + earth: Red, Black, Y/G
3 core + earth: Red, White, Blue, Y/G
4 core + earth: Red, White, Blue, Black, Y/G


Sheath: Red or according to customer requirements

Standard:
Cable design: AS/NZS5000.1
Conductor: AS/NZS 1125
Fire resistant : AS/NZS3013 (WS52W)
